Consew CN-897VC V-series High Speed Coverstitch Industrial Sewing Machine With Table and Servo Motor
Consew CN-897VC V-series High Speed Coverstitch Industrial Sewing Machine With Table and Servo Motor
reseller raitng
Product Pictures

Consew CN-897VC V-series High Speed Coverstitch Industrial Sewing Machine With Table and Servo Motor

SKU: CN-897VC
Weight: 90 lbs
Vendor: Consew
Our Price: $2299.99
There will be a surcharge of $150 if shipped to a residential address
Please, enter quantity for at least one product
Quantity unavailable. Try selecting a smaller quantity.

Consew CN-897VC V-series High Speed Coverstitch Machine Comes With Table, Legs, Servo Motor and LED Lamp

With Fully Automatic Lubrication, Differential Feed With , Micrometric Adjustment, Pushbutton Stitch Regulator, Thread Lubricating And Needle Cooling System

MACHINE APPLICATIONS:

  • For sewing light to heavy-weight materials.
  • Cylinder-bed for general seaming
  • Suitable for hemmimg, tape binding, elastic inserting, etc.

MACHINE FEATURES:

  • Speed, Max. up to 6000 s.p.m.*
  • Push-button stitch regulator
  • External cooling of oil supply
  • Fully automatic lubrication with visual flow controls
  • Lubricating oil continuously filtered by replaceable filter
  • Differential feed with micrometric adjustment for shirring and stretching.  Ratio up to 4 to 1.
  • Intermittent action possible
  • Standard type UY128GAS needles
  • Silicone based needle cooling and thread lubricating
  • CONFIGURATIONS:
    2 Needles,  2 Loopers,  4 Threads
    3 Needles,  2 Loopers,  5 Threads
  • NEEDLES:  Comes with 3-needle, 5.6 mm
    (Optional Needle Gauges available)
    2 Needles:    3.2, 4.0, 4.8, 5.6, 6.4 mm
    3 Needles:    5.6, 6.4 mm
  • MORE OPTIONS
    -UTA     • Under thread trimming device (pneumatic)
    -ST       • Top cover thread trimming device
    -UTM    • Under thread trimming device (electric)
    -W         • Thread wiper (electric)
    -EC       • Tape Cutter (electric)

MACHINE SPECIFICATIONS:

  • Number of Needles: 2, 3
  • Feeding Mechanism: Differential
  • Standard or Full Function: Standard Functions
  • Differential Ratio: 1 : 0.3 ~ 1 : 2.9
  • Workspace: Standard Workspace
  • Needle Bar Stroke: 31mm
  • Speed, Max (S.P.M.): 6000
  • Max Stitch Length: 1.4 ~ 3.6mm
  • Presser Foot Lift: 7.0mm
  • Needle Used: UY128GAS
  • Standard Distance Between Needles: 5.6mm 3-needle
  • Two Needle
    Needle Distances: Comes with 3-needle, 5.6 mm
  • Looper: 2

THE ADVANTAGES OF A SERVO MOTOR:

  • They use up to 90% less power than clutch motors
  • They are 1/3 lighter than clutch motors
  • With a flick of the switch you can reverse motor rotation
  • No parts to wear out or adjust.
  • No matter how hard you press the foot pedal configured speed remains the same

Because of Servo motor speed control, most users find the machine is easier to use.  Both beginning and seasoned sewers find this feature helpful when stitching projects that don't demand high-speed stitching.

DOWNLOADS:

U.S. WARRANTY:

90 Days labor on defects in materials and workmanship.

** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary.

Disclaimer: Due to the weight and shipping methods used for industrial machines they may experience marring and scratches during shipping. This will not affect the operation of the machine.
